COG 128X64 Graphic LCD Module

Manufacturer: SINDA
Product Name: 128x64 COG Graphic LCD Display | 128x64 Chip on Glass LCD Display

This 128x64 graphic chip-on-glass (COG) LCD shows blue pixels on a gray background. As a COG display, there's no PCB and the controller/driver is directly bonded to the glass of the display. The Liquid Crystal Display offers a wide operating temperature range from -20 to 70 degrees Celsius. The best view for this monitor is 6:00/12:00. The monitor operates on a 3.3V supply voltage and is RoHS compliant. Sinda Display is professional manufacturer of Monochrome LCD display for Industry application, include digital panel meter, UPS, inverter, multi-function meter, POS machines, Fuel Dispenser, Gas Dispenser, Flow Meter, KWH Meter, Energy Meter, Water Meter, Gas Meter, Smart Meter, Pump controller etc. For any other custom requests, feel free to contact us.

Inquire now back

Overview SERIES MODEL NO

ATTRIBUTES

Manufacturer	SINDA
Part Number	SDGG12864-07
Display Format	128x64 dots
Interface	SPI
IC or Equivalent	ST7567
Connection	FPC
Outline Dimension	80.00(W)x37.00(H)x5.30(T)mm
Visual Area	66.00x28.00mm
Active Area	61.42x24.94mm
Dot (Pixel) Size	0.46x0.37mm
Dot (Pixel) Pitch	0.48x0.39mm
IC Package	COG
Display Type	FSTN /STN. Gray/Yellow-Green/Blue
Viewing Direction	6:00/12:00
Power Supply(Typ)	3.3V
Operating Temperature	-20℃~70℃
Storage Temperature	-30℃~80℃

Display Format	Model No.	Outline Dimension	Viewing Area	Active Area	IC	Interface
128 x 64	SDGG12864-07	80.00(W)x37.00(H)x5.30(T)mm	66.00x28.00mm	61.42x24.94mm	ST7567	SPI
128 x 64	SDGG12864-16	61.80(W)x42.70(H)x5.30(T)mm	57.00x30.00mm	53.75x26.87mm	ST7565P	8-bit Parallel
128 x 64	SDGG12864-26	33.00(W)x26.10(H)x3.50(T)mm	28.00x17.00mm	26.22x14.70mm	UC1701X	SPI
128 x 64	SDGG12864-30	71.300(W)x28.30(H)x5.30(T)mm	66.50x38.00mm	60.78x32.94mm	ST7565R	SPI
128 x 64	SDGG12864-37	51.70(W)x36.00(H)x4.00(T)mm	47.10x26.50mm	44.78x22.38mm	ST7565R	SPI
128 x 64	SDGG12864-58	63.20(W)x41.70(H)x5.10(T)mm	50.00x25.00mm	46.05x23.01mm	ST7567	8-bit Parallel &SPI
128 x 64	SDGG12864-59	74.00(W)x41.70(H)x6.30(T)mm	50.00x25.00mm	46.05x23.01mm	ST7567	8-bit Parallel &SPI
128 x 64	SDGG12864-60	71.30(W)x48.20(H)x5.30(T)mm	66.50x38.40mm	60.78x32.94mm	ST7567	8-bit Parallel &SPI
128 x 64	SDGG12864-67SDGG12864-67	36.30(W)x24.00(H)x5.50(T)mm	29.00x16.35mm	25.58x14.06mm	ST7567	SPI
128 x 64	SDGG12864-68	77.40(W)x52.40(H)x6.00(T)mm	70.00x40.00mm	66.52x33.24mm	ST7565R	8-bit Parallel &SPI
128 x 64	SDGG12864-69	70.00(W)x43.00(H)x6.00(T)mm	58.00x29.50mm	55.00x27.48mm	ST7567	SPI
128 x 64	SDGG12864-70C	70.00(W)x43.00(H)x6.00(T)mm	58.00x29.50mm	55.00x27.48mm	ST7567	SPI
128 x 64	SDGG12864-72	26.70(W)x19.70(H)x2.70(T)mm	23.74x12.86mm	21.74x10.86mm	ST7567	SPI
128 x 64	SDGG12864-78	57.60(W)x40.50(H)x5.00(T)mm	53.60x28.60mm	48.61x24.93mm	ST7567	Parallel
128 x 64	SDGG12864-128	81.70(W)x74.50(H)x7.80(T)mm	70.00x40.00mm	66.52x33.24mm	ST7565	Parallel
128 x 64	SDGG12864-130	80.00(W)x54.00(H)x6.30(T)mm	70.70x38.80mm	66.52x33.24mm	ST7567	Parallel &SPI
128 x 64	SDGG12864-142	36.30(W)x24.00(H)x2.60(T)mm	29.00x16.35mm	25.58x14.06mm	ST7567	SPI
128 x 64	SDGG12864-168	66.00(W)x45.00(H)x5.40(T)mm	60.00x32.60mm	55.02x27.50mm	NT7538H	Parallel
128 x 64	SDGG12864-215C	43.60(W)x33.80(H)x2.20(T)mm	39.80x25.50mm	37.09x25.01mm	UC1601X	SPI
