RTP Resistive Touch Panel
Provide Customized Size RTP: ① High temperature and humidity, anti static ② G+G structure ③ Transmittance >78% ④ Anti dust, water ⑤ 4 line RTP
Human-machine interfaces are becoming increasingly important in modern control systems. Visual information is achieved through high-resolution, high-contrast and bright displays, which often require touchscreens. Touch panels are usually customised. This is because the touch panel forms a unit in combination with the protective glass. For any other custom requests, feel free to contact us.
Analog Resistive Touch Panel (RTP): it works well with almost any stylus-like object, and can also be operated with bared or gloved fingers.
| RTP | CTP | |
| Durability | Good | Excellent |
| Size | Small to Medium | Small to very big size |
| Requires Calibratio | Yes | No |
| Multi Touch | No | Yes |
| Operation with non-conductive object | Yes | No |
| Optical Transmittance | Hazy | High |
| Cost | Low | High |
| Power Consumption | Low | High |
Main Applications:
Industrial Application
Require gloved operation, waterproof, chemical environment resistant, impact resistant, anti-pollution and easy cleaning, etc.
Common-mode interference and long-term charged operation reliability should be taken into account if the touch screen is used in poor electrical environment.
Financial Terminal
Generally require long service life and security. Desktop financial terminal also with requirement of long-term charged use.
Outdoor Use
Generally require sunlight readable, waterproof, anti-drop.
Intelligent Home Kitchen
Require safety glass and high temperature.
Smart Home
Need to consider product integrity.
Main Technologies:
Anti-Glare (AG)
Improve glare phenomenon caused by mirror reflection of high light source on ordinary surface via rough surface treatment and diffuse reflection of incident
light.
Anti-Reflection (AR)
Reduce the reflectivity of incident rays.
Anti-Fingerprints (AS/AF)
Increase surface energy (usually measured by water contact angle greater than 110°) and improve surface cleanliness.
Anti-Fog
Touch Display with air bonding, apply anti-fog technology to the inner surface of the CTP to inhibit the generation of water fog caused by temperature change.
Waterproof, Gloved Operation and Common-mode Interference design
Provide appropriate solutions based on customer’s demand to realize capacitive touch operation in water vapor/water drop environment, gloved operation,
and common-mode interference resistant, etc.
High Reliability Design
Overall monitoring for design, production and quality control to ensure the product reliability and life time.
| Display Format | Model No. | Outline Dimension | Viewing Area | Active Area | IC | Interface | Datasheet Download |
|---|
