In the field of professional communication equipment, the display screen not only serves the function of information presentation but also directly affects the usability and reliability of the equipment in complex environments. To meet the project requirements of our German client, we custom-developed a 7-inch high-brightness TFT LCD display module with integrated capacitive touch (CTP), specifically designed for industrial-grade communication equipment.

Project Background

This German client specializes in the research and development and manufacturing of communication equipment. Their products are typically used in outdoor or semi-outdoor environments, placing high demands on the display system:

Moderate screen size, convenient for integration into the equipment panel

High-brightness display, ensuring clear readability in bright light environments

Sensitive touch operation, supporting stable human-machine interaction

Wide temperature range and environmental resistance, meeting industrial-grade usage scenarios

Compliant with European environmental and regulatory standards

Overview of the Customized Display Solution

Based on the above requirements, we customized a 7.0-inch TFT LCD + CTP integrated display solution for the client, comprehensively optimizing display performance, structural reliability, and system compatibility. TFT LCD Display Parameters

Display Size: 7.0 inch

Resolution: 1024 × 600

Display Mode: Transmissive, Normally Black

Viewing Direction: All O’Clock

Driver IC: Built-in

Interface Type: RGB

Brightness: 1000 cd/m² (TYP)

Brightness Uniformity: ≥80% (MIN)

Backlight Solution: 42 white LEDs

IF = 300 mA

VF = 8.4 V – 9.6 V

Operating Temperature: -20℃ ～ +70℃

Storage Temperature: -30℃ ～ +80℃

Environmental Requirements: RoHS compliant

CTP Capacitive Touch Parameters

Structure: G + G

Control IC: FT5446

Operating Voltage: 3.3 V

Transmittance: ≥85%

Surface Hardness: ≥6H

Operating Environment: -20℃ ～ +70℃, Humidity 20%～90%

Storage Environment: -30℃ ～ +80℃, Humidity 20%～90%

Untoleranced Dimensions: ±0.2 mm

Solution Advantages and Application Value

1. 1000 nits High-Brightness Display, suitable for outdoor communication equipment

The high-brightness TFT LCD ensures clear visibility even in strong light or complex lighting conditions, meeting the core requirements of reliable display for communication equipment.

2. Integrated TFT + CTP Design

The capacitive touch and display module are highly integrated, resulting in a compact structure and improved overall reliability and assembly efficiency.

3. Industrial-Grade Wide Temperature Performance

Both the display and touch functions maintain stable operation in cold or high-temperature environments, suitable for diverse application scenarios in Europe.

4. Highly Durable Touch Glass

≥6H surface hardness effectively improves scratch resistance and extends the service life of the device.

5. Compliant with European Market Regulations

The overall solution meets RoHS environmental standards, facilitating the smooth entry of customer products into the German and EU markets.

Project Achievements

This 7-inch high-brightness CTP TFT display module has completed sample confirmation and reliability testing and has been successfully applied to the customer's communication equipment products. The customer highly praised the display brightness, touch response, and overall stability, and has entered into subsequent projects and long-term cooperation.

Summary

Through in-depth analysis of the application scenarios for communication equipment, we successfully delivered a customized 7-inch CTP TFT display solution with high brightness, strong environmental adaptability, and reliable performance to our German customer.

This case fully demonstrates the core value of customized TFT LCDs in the industrial and communication equipment fields.

If you are looking for a 7-inch TFT LCD, high-brightness TFT display, or CTP touch display customization solution, please feel free to contact us for further discussion.
