In the fiercely competitive field of TFT display technology, "TFT display test" is a key link to ensure that products stand out. Our customized TFT display screen, with ten rigorous testing processes, not only meets the needs of diverse applications, but also sets a benchmark in the market with excellent quality.

Full process quality control, ensuring accuracy from the source

In the raw material and basic performance testing stage, the image measuring instrument plays a vital role. It accurately measures the dimensions of the display glass substrate, frame, etc. through optical imaging to ensure that the component accuracy error is controlled within ±0.01mm. This key step effectively avoids subsequent assembly deviations. According to industry data, the product defect rate caused by dimensional error can be reduced by more than 60%. At the same time, the microscopic inspection of the microscope is also indispensable. It can accurately detect foreign matter on the screen surface, inside and at the cable pressing point, even tiny impurities of 0.01mm level cannot escape, and the influence of process pollution on the display effect is eliminated from the source.

The electric pencil hardness tester focuses on the wear resistance test of the screen surface. Scratching with pencils of different hardness at specific angles and pressures simulates the wear and tear scenarios in daily use, ensuring that the glass cover or touch screen coating can withstand long-term tests. For example, the surface hardness of a certain industrial TFT display screen that has been tested has reached 6H level, far exceeding the 3H - 4H standard of ordinary displays, significantly improving the durability of the product in complex operating environments.

Multi-dimensional functional testing to ensure stable operation

After completing the basic structure inspection, the display screen will enter the functional and environmental adaptability test phase. The brightness meter accurately measures the optical parameters of the screen, such as brightness, contrast and uniformity, to ensure that the brightness uniformity of the screen is ≥95% and the color reproduction reaches professional standards. This test is particularly important for fields such as medical equipment and commercial advertising that have extremely high requirements for display effects.

The constant temperature and humidity test chamber simulates extreme environmental changes from - 40℃ low temperature to 85℃ high temperature and humidity 0 - 95% RH, fully verifying the stability of the display screen under different climatic conditions. After 1000 hours of constant temperature and humidity testing, a certain in-vehicle TFT display can still maintain normal display, which fully proves its reliable performance in complex climate environments.

In addition, the electrostatic discharge generator simulates electrostatic shock scenarios up to ±15kV to detect the display's anti-static interference ability, effectively avoiding pixel abnormalities or chip failures caused by static electricity, and protecting the daily use of electronic products.

Extreme environmental challenges to verify durable quality

To ensure the durability of the product in actual use, mechanical and environmental durability tests become the last quality checkpoint. The drop ball impact tester evaluates its ability to resist accidental impact by allowing steel balls of different weights to fall freely from a specific height and hit the screen. After testing, our display can still work normally after withstanding the impact of a 500g steel ball falling from a height of 50cm, showing strong structural strength.

The simulated transport vibration table simulates the bumps and vibrations during product transportation, vibrating continuously for 12 hours at a frequency of 2-5Hz and an amplitude of 5-10mm to detect whether the internal component connections are stable and effectively avoid loosening and damage caused by vibration.

For displays used in outdoor or special environments, the boiling test immerses the screen in 100℃ boiling water for 30 minutes to test its waterproof sealing; the salt spray test chamber simulates the marine or industrial salt spray environment, spraying 5% concentration salt water for 48 hours continuously to evaluate the corrosion resistance of the shell and circuit board. After the salt spray test, a certain outdoor advertising TFT display screen had no rust on the surface and the circuit functioned normally, which fully proved its long-term reliability in harsh environments.

We always adhere to the strict "TFT display test" process as the core, combined with a wealth of customized options, including wiring, cover, touch screen, etc., to provide customers with personalized solutions. Each TFT display screen has been tested for hundreds of indicators, speaking with data and proving with quality. Choosing us means choosing excellent display products that can stand the test of the market and time.
